CICADA AUDIO FLX700.4

SPECIFICATIONS

4 Channel (14.4v)-RMS Power Output:

120w x 4 @ 4 Ω stereo

175w x 4 @ 2 Ω stereo

2 Channel Bridged Mode (14.4v):

350w x 2 @ 4 Ω -RMS Power Output

SNR: 91dB (A-weighted, 20 Hz – 20 kHz)

Operating Voltage: 9v – 16v

Current Draw (Music): 50 A

Current Draw (Max): 80 A

Recommended Fuse (Music): 50 A

Total Efficiency: 80%

Frequency response 20 Hz – 20 kHz +/- 3 dB

Damping Factor: 200

Crossover LPF/FULL/HPF: 20 – 20kHz

Slope: 6/12/24/48 dB per octave

Gain: 0.2 V – 12 V

Turn-On Configuration: REM/DC/VOX

THD + N (10% Rated Power): 0.1% @ 2 Ω per channel

Dimensions (Mounting Brackets): 5.3 x 4.9 x 2.0-inch, 134 x 125 x 51mm

Dimensions (Chassis): 4.1 x 4.9 x 2.0-inch, 104 x 125 x 51mm
